Ceramic facade cladding is an innovative solution used in modern buildings to provide aesthetics, durability, and thermal insulation for exterior surfaces. The system begins with selecting the preferred ceramic or granite material, followed by thermal insulation on the building’s blind facades, integrating it with sub-carrier aluminum constructions.

Ceramic facade claddings are stain-resistant, unaffected by atmospheric changes, and have high heat resistance, offering a long-lasting building solution. There are three main installation methods:



1. Clipped System

In this system, ceramics are mounted onto carrier aluminum profiles using visible stainless steel clips and EPDM gaskets. It is an economical and reliable system applicable to ceramics of all sizes. The advantages of the clipped system include:

• Fast and practical installation.

• Easy disassembly and reinstallation when needed.

• Long-lasting due to mechanical installation and resistance to high wind loads.

2. Concealed Channel System

In this system, ceramics are fixed to the carrier construction using aluminum clips inserted into swallowtail channels carved into the back surface at four points. It is generally applied to materials with dimensions of 60×60 cm, 60×120 cm, and 50×100 cm. Its advantages include:

• Aesthetic appearance since the clips are hidden.

• Secure mechanical connection with minimal risk of falling.

• High durability, making it suitable for different architectural designs.

3. Adhesive System

Ceramics are mounted onto aluminum carrier profiles using auxiliary temporary tape and a high-strength polyurethane-based adhesive that maintains elasticity between -40° and +100°C. This is one of the most economical porcelain ceramic application methods and can be applied to ceramics of all sizes. There are two application types:

• Open Joint System: Applied with gaps between joints to enhance air circulation and allow the structure to breathe.

• Closed Joint System: Special aluminum profiles in the desired RAL color are installed between joints, providing a seamless appearance.

Advantages of Ceramic Facade Claddings

• Durability: Ceramic materials are resistant to UV rays, chemical effects, and weather conditions.

• Low Maintenance: They do not retain dirt or stains, minimizing cleaning requirements.

• Thermal Insulation: When used with additional insulation layers, they contribute to energy efficiency.

• Fire Resistance: Classified as A1 non-combustible material, ensuring fire safety.

• Aesthetic Versatility: Offers a variety of colors, textures, and surface options, allowing architectural flexibility.

Due to their high durability and aesthetic properties, ceramic facade cladding systems are increasingly preferred in the modern construction industry. The application method should be chosen based on the building’s design, budget planning, and technical requirements.
