STRUCTURAL GLAZING

STRUCTURAL GLAZING



As Polmek Group, we provide quality products and services to our customers from the application of structural silicone facade systems to the manufacturing process.

Structural Silicone Façade systems are modern facade cladding systems that show the simplicity and nobility of glass. In the structural silicone facade system, an aluminum profile is not seen from the outside, and a completely glass appearance is created for the building. Structural Silicone curtain wall system is the most preferred facade system as it gives prestige and modern appearance to buildings.

Since the joining processes on the silicone façade are provided with EPDM roving or special silicone from three points, it is very functional in terms of both durability and heat insulation, and at the same time, it guarantees a definite seal between the glass.
We offer professional solutions in accordance with international standards in the assembly and production of Curtain wall systems.


What we do?

• Manufacturing of Structural Glazing systems
• Turnkey on-site installation
• Standard and complex façade solutions
• System design and engineering
• Static and performance calculations
• Quality control and testing
• Logistics and site coordination
• Sealing, insulation, and finishing works


• Vertical and horizontal profiles in the system are equipped with condensation channels

• Air and Water Tightness

• Thermal Insulation

• Fire Resistance and Safety

• Easy Installation and Application

• Aesthetic and Coating Options

• Wide Glazing Capacity and Glass Options

• Resistance to Earthquake and Wind Loads

• Modular Design and Flexibility

• Low Maintenance and Long-Term Durability

• Seamless Glass Appearance on Facades

• Ease of Manufacturing and Assembly

• Aluminum profiles available in all RAL, anodized, and wood-effect finishes

• Environmentally Friendly Materials and Sustainability


Polmek Group specializes in designing and developing facade systems that meet the challenging technical requirements associated with architects' innovative and complex geometries. Treating each project as a unique case, Polmek Group prioritizes feasibility and ease of use in the design of customized facade systems.

As a leading system designer and pioneer of innovations in facade technologies, Polmek Group has completed over 800 successful projects and gained extensive experience in designing the most complex facades and skylights in international markets. Consequently, Polmek Group has the capacity to offer architectural facade solutions compliant with nearly all international standards.

Advanced & Complex Façade Solutions
  • Single Layer Free Form Structures
  • Unitized Curved & Bended Façades
  • Inward Inclined Façades with vents in it (Challenge to Rain)
  • Twisting Façades
  • Intelligent Façades
  • Crystalline Shaped Façades
  • Triangulated Free Form Surfaces
  • All Types of Multiple Skinned Façades
  • Cable Suspension Façades

Our company provides integrated facade systems and advanced building exterior solutions for projects such as commercial, residential, stadiums, sports complexes, and shopping centers. Especially for medium and large-scale projects, our company offers turnkey production and installation services, managing facade manufacturing and facade installation processes under a single coordination. Each project is developed as a unique architectural system with professional facade design, detailed solutions, and a performance oriented engineering approach.

Production and Installation
In accordance with detail-oriented and high-precision production procedures, we carry out our CNC production processes with aluminum and steel profile processing, offering reliable solutions for the most complex projects. Within the scope of our turnkey installation service, we successfully complete site management and project completion processes with effective planning and rapid implementation principles alongside our expert installation team.

Polmek Group delivers turnkey façade design, manufacturing, and installation services for structural glazing systems. Tempered, laminated, and insulated glass solutions are professionally integrated into projects by our expert façade teams. All application and installation processes are executed to the highest standards of quality.
Structural silicone curtain wall systems protect buildings from external air flow and water leaks with infrastructure channels. Depending on the weather conditions, it has silicone and filters that prevent the hot and cold air inside the building from leaking out. It protects the interior of the building from sunlight thanks to its heat-resistant glass with U (W/m2K) values. Thanks to its highly insulated structure, the silicone facade system provides fuel savings to buildings by balancing the room temperature by eliminating heat loss.


  • Tempered Glass

  • Laminated Glass

  • Tempered + Laminated Glass

  • Insulated Glass

  • Low-E Coated Glass

  • Reflective Glass

  • Screen-Printed Glass

  • Tinted Glass

  • Solar Glass (BIPV – Photovoltaic Glass)



STRUCTURAL GLAZING TECHNICAL Q&A

What is Structural Glazing? It is a façade system where glass panels are fixed to aluminum or steel supporting profiles with high-strength silicone, providing a seamless and engineering-controlled façade.
How does the installation process proceed? Substructure installation, temporary placement of glass panels, application of structural silicone, and sealing with performance testing are performed.
As a façade company, what solutions do we provide? We manufacture, supply, and perform on-site installation of Structural Glazing façades, including silicone application, thermal break profiles, and façade performance verification.
What advantages does Structural Glazing offer? Seamless glass appearance, natural light optimization, wind and load resistance; thermal break profiles provide energy efficiency.
Does the system contribute to energy efficiency? Yes, heat loss is reduced with low-e glass and insulated profiles, increasing façade energy performance.
Is it compatible with other curtain wall types? Yes, it can be integrated with unitized or stick curtain wall solutions, ensuring façade integrity and ease of installation.
Is customized design possible? Glass type, silicone color, profile section, and panel dimensions can be applied according to project-specific engineering criteria.
In which types of buildings is this system preferred? It is used in offices, shopping centers, hotels, and high-rise corporate buildings with a focus on aesthetics and performance.
Can metal façades or ceramic cladding be used with Structural Glazing? Yes, different materials can be integrated with Structural Glazing panels, providing design flexibility.
Is the system compatible with sun breakers and glass support systems? Yes, sun breakers, spider glass, or other glazing elements are integrated according to engineering calculations for load transfer and joint alignment.
Which standards are applied in production and installation? Production: EN 12150, EN 1279, EN 13830, ASTM C1184; Installation: EN 1991 and ASTM E1300 standards are followed.
What are the Pa values? Pa values and wind loads vary according to the project and are determined through engineering calculations.
Depending on the size and detail of the project, the production time varies.
