STRUCTURAL GLAZING

STRUCTURAL GLAZING


Structural Silicone Facade Systems are modern facade cladding solutions that emphasize the simplicity and aesthetics of glass. In this system, glass panels are fixed to the load-bearing aluminum structure with high-strength structural silicone, and when viewed from the outside, a seamless glass surface appearance is achieved.

In the Structural Glazing system, the load-bearing connection between the glass and aluminum is provided by structural silicone, while EPDM gaskets are used as auxiliary elements for air and water tightness. In this way, the system offers both high strength and superior insulation performance.

We provide professional solutions in the design, production, and installation processes of curtain wall systems in accordance with international standards.


What we do?

• Manufacturing of Structural Glazing systems
• Turnkey on-site installation
• Standard and complex façade solutions
• System design and engineering
• Static and performance calculations
• Quality control and testing
• Logistics and site coordination
• Sealing, insulation, and finishing works


• Air and Water Tightness

• Thermal Insulation

• Fire Resistance and Safety

• Easy Installation and Application

• Aesthetic and Coating Options

• Wide Glazing Capacity and Glass Options

• Resistance to Earthquake and Wind Loads

• Modular Design and Flexibility

• Low Maintenance and Long-Term Durability

• Seamless Glass Appearance on Facades

• Ease of Manufacturing and Assembly

• Environmentally Friendly Materials and Sustainability


Polmek Group specializes in designing and developing facade systems that meet the challenging technical requirements associated with architects' innovative and complex geometries. Treating each project as a unique case, Polmek Group prioritizes feasibility and ease of use in the design of customized facade systems.


Each project is treated as a unique case by Polmek Group, prioritizing applicability and ease of use in the design of customized façade systems. Polmek Group has completed medium and large-scale projects and has gained extensive experience in the design of the most complex façades and roof windows in international markets. Polmek Group, with its innovative vision capable of providing all architectural façade solutions, always aims to develop innovative, high-performance and sustainable architectural façade solutions in compliance with international standards.


Advanced & Complex Façade Solutions
  • Single Layer Free Form Structures
  • Unitized Curved & Bended Façades
  • Inward Inclined Façades with vents in it (Challenge to Rain)
  • Twisting Façades
  • Intelligent Façades
  • Crystalline Shaped Façades
  • Triangulated Free Form Surfaces
  • All Types of Multiple Skinned Façades
  • Cable Suspension Façades

Our company provides integrated facade systems and advanced building exterior solutions for projects such as commercial, residential, stadiums, sports complexes, and shopping centers. Especially for medium and large-scale projects, our company offers turnkey production and installation services, managing facade manufacturing and facade installation processes under a single coordination. Each project is developed as a unique architectural system with professional facade design, detailed solutions, and a performance oriented engineering approach.

Production and Installation
In accordance with detail-oriented and high-precision production procedures, we carry out our CNC production processes with aluminum and steel profile processing, offering reliable solutions for the most complex projects. Within the scope of our turnkey installation service, we successfully complete site management and project completion processes with effective planning and rapid implementation principles alongside our expert installation team.

Polmek Group provides turnkey installation services for structural glazing façade systems, covering structural analysis and application coordination.

Structural silicone curtain wall systems protect buildings from external air flow and water leaks with infrastructure channels. Depending on the weather conditions, it has silicone and filters that prevent the hot and cold air inside the building from leaking out. It protects the interior of the building from sunlight thanks to its heat-resistant glass with U (W/m2K) values. Thanks to its highly insulated structure, the silicone facade system provides fuel savings to buildings by balancing the room temperature by eliminating heat loss.


  • Tempered Glass

  • Laminated Glass

  • Tempered + Laminated Glass

  • Insulated Glass

  • Low-E Coated Glass

  • Reflective Glass

  • Screen-Printed Glass

  • Tinted Glass

  • Solar Glass (BIPV – Photovoltaic Glass)



STRUCTURAL GLAZING TECHNICAL Q&A

What is Structural Glazing? It is a façade system where glass panels are fixed to aluminum or steel supporting profiles with high-strength silicone, providing a seamless and engineering-controlled façade.
How does the installation process proceed? Substructure installation, temporary placement of glass panels, application of structural silicone, and sealing with performance testing are performed.
As a façade company, what solutions do we provide? We manufacture, supply, and perform on-site installation of Structural Glazing façades, including silicone application, thermal break profiles, and façade performance verification.
What advantages does Structural Glazing offer? Seamless glass appearance, natural light optimization, wind and load resistance; thermal break profiles provide energy efficiency.
Does the system contribute to energy efficiency? Yes, heat loss is reduced with low-e glass and insulated profiles, increasing façade energy performance.
Is it compatible with other curtain wall types? Yes, it can be integrated with unitized or stick curtain wall solutions, ensuring façade integrity and ease of installation.
Is customized design possible? Glass type, silicone color, profile section, and panel dimensions can be applied according to project-specific engineering criteria.
In which types of buildings is this system preferred? It is used in offices, shopping centers, hotels, and high-rise corporate buildings with a focus on aesthetics and performance.
Can metal façades or ceramic cladding be used with Structural Glazing? Yes, different materials can be integrated with Structural Glazing panels, providing design flexibility.
Is the system compatible with sun breakers and glass support systems? Yes, sun breakers, spider glass, or other glazing elements are integrated according to engineering calculations for load transfer and joint alignment.
Which standards are applied in production and installation? Production: EN 12150, EN 1279, EN 13830, ASTM C1184; Installation: EN 1991 and ASTM E1300 standards are followed.
What are the Pa values? Pa values and wind loads vary according to the project and are determined through engineering calculations.
Depending on the size and detail of the project, the production time varies.
